| Item | YL-F102C |
| Physical Parameter | |
| Size |
132(L) x 98(W) x 30(H) mm (Exclude bracket and external wires)
|
| Shell material | ABS |
| Antenna housing color | Sky blue |
| UHF RFID Performance Parameter | |
| Frequency |
865-868MHz/902-928MHz
|
| Protocol |
ISO18000-6C
|
| Built-in antenna |
PCB board antenna
|
| Power |
0-26dBm (adjustable by 1dBm step with CPH demo software)
|
| R/W range |
≤30cm
|
| Group read rate |
1~10pcs EPC tag
|
| Working areas |
US, Canada and other regions following U.S. FCC Part 15 regulation,Europe and other regions following ETSI EN 302 208 regulations,Mainland China,Japan,Korea,Malaysia,Taiwan
|
| Electric Parameter | |
| Interface |
Standard: USB
Optional: USB virtual keyboard output
|
| Reading indicator | Buzzer |
| Power consumption |
~1W
|
| Power supply |
USB powered
|
|
Application Software
|
API development kit and application routine based on Windows
|
|
SDK
|
C#, C++,Delphi, VB, Java,Python
|
|
Operating Environment
|
|
|
Operating Temperature
|
-10℃～+55℃
|
|
Storage Temperature
|
-20℃～+75℃
|
|
Humidity
|
20%～95% RH, non condensing
|
|
Lighting protection
|
DC ground
|
|
Accessories
|
|
|
Standard
|
USB cable
|
